20ft Expandable Prefab Container House
20ft Expandable Prefab Container House – Foldable, Durable & Eco-Friendly
Mobile Living Redefined for Modern Lifestyles
This High-Quality 20ft Mobile Expandable Container House brings together innovation and practicality in one foldable modular unit. Designed for flexibility and transport efficiency, it expands from a compact delivery mode into a full-sized, livable villa with up to four bedrooms, kitchen, and bathroom.
Backed by CE certification, this house complies with European Union safety standards and is ideal for villas, hotels, farmhouses, apartments, and off-grid housing projects.
Key Product Features
| Feature |
Benefit |
| Expandable Structure |
Folds into a compact unit for transport; unfolds into a spacious home |
| Galvanized Steel Frame |
Corrosion-resistant and long-lasting under all weather conditions |
| Sandwich Panel Walls |
Waterproof, fire-resistant, and insulated for comfort and safety |
| Custom Colors & Layouts |
Choose your preferred finish and internal room configuration |
| Eco-Friendly Design |
Built with sustainability in mind; supports solar-powered upgrades |
| CE Certified |
Complies with EU safety and quality assurance regulations |
| Fast Installation |
Pre-engineered for plug-and-play setup with minimal labor requirements |
Applications
| Use Case |
Suitability |
| Private Villas |
Expandable homes in rural, semi-urban, or beachfront locations |
| Hotels |
Modular resort accommodation for eco-lodges and retreats |
| Farmhouses |
Ideal for agricultural or countryside living |
| Apartments |
Micro-living and rental investments in growing communities |
| Disaster Relief |
Emergency shelters and fast-deploy housing |
Technical Specifications
| Component |
Specification |
| External Dimensions (mm) |
5900 × 6300 × 2480 |
| Internal Dimensions (mm) |
5460 × 6140 × 2240 |
| Folding State (mm) |
5900 × 2200 × 2480 |
| Wall Thickness Options |
50mm / 75mm / 100mm |
| Standard Size (Optional) |
L11800 × W6220 × H2480 mm |
| Main Material |
Sandwich Panels + Galvanized Steel Frame |
| Structure Shape |
Rectangle (Expandable and Foldable) |
| Model Number |
01 |
| MOQ |
1 unit |
| Warranty |
5 years |
| After-Sale Support |
Online technical assistance |
Structural Breakdown – Frame Engineering
| Frame Section |
Material & Dimensions |
| Top Side Rail |
80 × 100 × 2.5 mm Galvanized Square Pipe |
| Top Beam |
2.5 mm Galvanized Bent Steel |
| Top Longitudinal Secondary Beam |
30 × 30 × 1.3 mm Galvanized Square Pipe |
| Top Transverse Secondary Beam |
40 × 60 × 1.5 mm Galvanized Square Pipe |
| Bottom Side Beam |
80 × 100 × 2.5 mm Galvanized Square Pipe |
| Bottom End Beam |
Galvanized Bend – 2.5 mm thick |
| Bottom Longitudinal Secondary Beam |
40 × 80 × 1.5 mm Galvanized Square Pipe |
| Bottom Transverse Secondary Beam |
40 × 80 × 1.5 mm Galvanized Square Pipe |
| Hanger |
6mm Galvanized L210 × W150 × H160 mm |
| Steel Column |
Galvanized Bend – 2.5 mm thick |
Customization Options
- Colors: Fully customizable exterior and interior finishes
- Bedrooms: Layout from 1 to 4 rooms + kitchen and bathroom
- Energy Upgrade: Optional solar power system
- Doors/Windows: Flexible placement and material options
- Use Case Design: Tailored internal partitioning for hospitality, residential, or utility functions
Packaging and Delivery
| Item |
Details |
| Selling Unit |
Single item |
| Package Size |
605 × 243 × 259 cm |
| Gross Weight |
2100 kg |
| Minimum Order |
1 unit |
