Waterproof and Windproof Apple Cabin Prefab Home Insulated for All Seasons Use
Apple Cabin Prefab Home – Waterproof & Windproof, Insulated for All-Season Use
Precision-Built for Year-Round Living
The Apple Cabin Prefab Home is designed as a multi-functional mobile container house optimized for extreme weather conditions. Built on a galvanized square tube steel frame, it combines structural strength, thermal insulation, and waterproofing in one compact unit. Its windproof profile, layered walls, and hollow tempered glass make it ideal for both urban and remote deployments — from mobile shops to guard cabins or full residential dwellings.
Fully compliant with CE certification standards, this modular housing solution ensures your structure meets EU safety codes, offering confidence for both residential and commercial applications.
Configuration Options and Sizing
| Model | External Dimensions (L x W x H) |
|---|---|
| 20FT | 5800 mm × 2150 mm × 2450 mm |
| 40FT | 11800 mm × 2150 mm × 2450 mm |
| Custom | Available upon request |
Structural Materials and Frame Details
| Component | Specifications |
|---|---|
| Main Frame | Galvanized square tube 100×100×2.5 mm / 50×100×1.5 mm |
| Wall Bracing | 40×60×1.2 mm + 30×50×1.2 mm (Horizontal), Diagonal bracing at corners |
| Roof Frame | Reinforced with 50×100×1.5 mm square pipes |
| Ground Substrate | 18 mm high-density cement pressure plate |
| Flooring | 10 mm composite wood with skirting |
| Elbow Frame | Semi-circular steel 100×100×2.5 mm |
Wall and Insulation Layers
| Section | Material Composition |
|---|---|
| Exterior Wall | 18 mm metal carved board |
| Interior Wall | 8 mm Stone Plastic Plate + adhesives and trims |
| Thermal Insulation | Rock wool roll felt with tin foil, thickness options from 5 to 15 cm |
| Insulation Rating | Up to R 3.2 for thermal efficiency |
Glazing & Environmental Sealing
| Windows | 5+12+5 mm hollow tempered glass with reinforced 40×80×1.5 mm square tube |
|---|---|
| Sealing System | Windproof and waterproof installation, CE-compliant |
Electrical & Safety Systems
| Component | Specification |
|---|---|
| Internal Wiring | Main line: 6 mm² copper wiring, 16A-rated sockets |
| Sockets & Switches | 3-hole & 5-hole sockets, single/double-opening switches |
| Protection Devices | Circuit breaker & leakage protection, digital control |
| Lighting | LED ceiling lights, line lights, optional tube lights |
Bathroom Configuration (Optional)
Equipped to deliver full residential functionality with:
- Aluminum alloy door
- Wet-dry partition
- Toilet, washbasin, showerhead, optional bathtub
- Internal water supply and drainage pipeline system
Terrace (Optional Add-On)
| Frame | Galvanized tube: 100×100×2.0 mm, 50×100×1.5 mm, 40×60×1.2 mm, 30×50×1.2 mm |
|---|---|
| Flooring | Wood plastic composite decking |
Staircase Options
Select from:
- Straight staircase
- Corner staircase
- Spiral staircase
Each stair is built with structural-grade materials to complement your selected configuration.
Versatile Applications
- Residential Housing: Perfect for mountain retreats, lakefront getaways, or minimalist permanent dwellings
- Mobile Retail or Cafés: Weather-proof pop-up shops or cafes in urban or event-driven settings
- Guard Houses or Checkpoints: Durable enough for military, industrial, or campus use
- Carports or Modular Storage: Weather-sealed enclosures for equipment or vehicles
- Remote Work Pods: Customized for power, insulation, and workspace comfort
Additional information
| Sizes | 20FT, 40FT |
|---|
