TOPPRE Detachable Office Container House
TOPPRE Detachable Office Container House – Modular 3 Bedroom Office Building (20ft/40ft)
Engineered for Flexibility, Durability, and Comfort
The TOPPRE Detachable Office Container House is a high-performance modular structure designed for long-term residential or commercial use. It is built with a fully galvanized steel frame, multiple waterproofing layers, sound insulation, and heat-preserving walls — ensuring year-round comfort, durability, and regulatory compliance.
This modern-style detachable unit is available in standard or customized sizes, making it suitable for deployment as office buildings, staff quarters, disaster relief housing, dormitories, or luxury mobile villas. TUV, CCC, CE, CPR, SAA, and UL certifications guarantee global safety compliance.
Specifications and Design Options
| Parameter | Details |
|---|---|
| External Dimensions | L6055 mm × W3000 mm × H2896 mm (Custom available) |
| Internal Dimensions | L5835 mm × W2780 mm × H2550 mm |
| Weight | Approx. 1250 kg |
| Layers (Stacking) | Up to 3 levels |
| Design Style | Modern, Stylish |
| Use Case | Residential, Commercial, Emergency, Hospitality |
| Available Colors | White (standard), Custom options available |
| Shape | Rectangular, Detachable Type |
| Floor Load | 2.0 kN/㎡ |
| Roof Load | 0.75 kN/㎡ |
| Wind Load | 1.0 kN/㎡ |
| Anti-Seismic Rating | Fortified up to Intensity 9° |
Structural Materials and Features
| Component | Material & Properties |
|---|---|
| Main Frame | Galvanized steel, anti-rust coating |
| Wall Panels | EPS/sandwich panel, thermal and sound insulation |
| Roofing | Three-layer waterproof treatment with sealing integrity |
| Floor Base | Engineered to support high floor loads |
| Door | Steel security-grade |
| Window | Plastic steel frame, anti-theft bars, mosquito netting |
Thermal and Acoustic Performance
Heat Preservation: Multilayer insulated sandwich panels prevent heat loss
Sound Insulation: Interior and exterior panels designed for acoustic dampening
Waterproofing: 3+ layer waterproofing measures for 100% leak prevention
Breathability: Wall configuration allows moisture release while maintaining indoor comfort
Certifications and Reliability
Certified to meet global compliance standards for modular housing:
- TUV (Technical Inspection Association)
- CE (European Conformity)
- CCC (China Compulsory Certification)
- CPR (Construction Products Regulation)
- SAA (Australian Standards)
- UL (Underwriters Laboratories)
These accreditations ensure market access, product safety, and trust in international deployments.
Electrical and Drainage Systems
| System | Details |
|---|---|
| Electric Plan | Fully designed internal wiring and breaker protection |
| Outlets & Switches | Included (layout customizable) |
| Drainage | Pre-integrated system plan with connection blueprints |
| Lighting | Optional LED ceiling and tube lights, switch configuration |
Advantages at a Glance
- Antirust Frame – Fully galvanized and industrially painted
- 100% Waterproof – Triple-layered treatment with sealed joints
- Installation-Friendly – Requires no crane or forklift
- Efficient Shipping – Up to 15 units fit in a single 40HQ container
- Custom Layout Support – In-house technical team for custom layout plans
- Low Maintenance – Smooth surface finishes, easy cleaning, and long wear resistance
Modular Applications
- Offices & Meeting Rooms
- Temporary Commercial Stores & Cafés
- Hospitals & Medical Units
- Emergency Relief Housing
- Workshop Facilities & Storage Units
- On-Site Accommodation for Project Camps
- Villas, Guest Houses, and Retail Kiosks
Additional information
| Sizes | 20Ft, 40FT |
|---|
